Product Details:
|
| Voltage: | 24-48V | Power: | 30-1000W |
|---|---|---|---|
| Speed: | 1000-3000rpm | Type: | PMDC Motor |
| Highlight: | 300w Permanent Magnet Brushed DC Motor,500w Permanent Magnet Brushed DC Motor,brushed dc motor high torque 24v |
||
Weeding Equipment Brushed DC Motor For Lawn Mower 24V 48V 300W 500W High Torque Power
Introduction
Our motor products are customized according to customer needs.
There are many kinds of products, so we need you to provide specific parameters
for our technicians to help you select and recommend appropriate products.
Quick Details
Brushed DC motor series
Diameter 30mm to 110mm
Power 5w to 1000w
Options:
Customized options: voltage, winding, shaft outlet, installation, outgoing line, etc.
EMI/RFI suppression circuit can be customized; Thermal protector
Install the gearbox, encoder, brake, etc
Application
Leisure sports vehicles (ATV, kart, off-road motorcycle, etc.)
Electric elderly scooter Electric wheelchair
Electric sanitation cleaning vehicle, cleaning vehicle
Heavy duty electric tricycle/electric motorcycle
Electric logistics carrier, forklift
Sightseeing bus, four-wheel scenic spot electric bicycle
Garden equipment (electric riding mower, crawler mower)
Sports and health products (massager, fat throwing machine, treadmill, etc.)
Electric four-wheel skateboard, electric scooter, etc
| Model | 90ZYT01A | 90ZYT-180 | 90ZYT02A |
| Rated Voltage V dc | 24v (option for 12v up to 60vdc) | ||
| Rated Speed rpm | 3000 | 3000 | 3000 |
| Rated Torque N.m | 1.2 | 1.6 | 1.8 |
| No Load Speed rpm | 3600 | 3500 | 3600 |
| Weight kg | 3.5 | 4.0 | 4.5 |
| Motor Length mm | 155 | 180 | 199 |
| Output Power W | 377 | 503 | 565 |
